Caterpillar

BR115 Brushcutter

Cat® Brushcutters are used to clear land and overgrowth.

Media

Studio Shot

Front View

Top View

Left View

Rear View

Bottom View

Right View

Cat® BR172 Brushcutter and 259D Compact Track Loader in a Landscaping Application

Cat® BR172 Brushcutter in a Landscaping Application

Cat® Brushcutter Attachments at Work

Cat® Brushcutter Attachment Overview

Cat® Brushcutter Attachment Operating Tips

An Attachment for Every Job – Cat® Work Tool Attachments

Exterior

Model shown represents features on all Cat® Brushcutters except where indicated.

Documents

Cat® Brushcutter Brochure

Get more info

First Name*
Last Name*
Company
Address 1*
Address 2
City*
County*
State*
Zip code*
Phone*
Email*
Hidden
Quote Information
Message or additional info
CAPTCHA
How did you hear about us?*
*If you chose Referral or Other, please explain below.
Email
This field is for validation purposes and should be left unchanged.

Features

Application

Blades and Blade Carriers

Long Life Motors and Gears

Motor Protection Guard

Galvanized Coil Chains

Heavy-Duty Skids

Specifications

US Metric

General

Spec	Value
Overall Width	62 in 1575 mm
Cutting Width	60 in 1524 mm
Maximum Cutting Diameter	3 in 76 mm
Required Hydraulics	Standard Flow Standard Flow
Overall Length	73 in 1854 mm
Overall Height	21 in 533 mm
Weight	950.2 lb 431 kg
Optimal Hydraulic Flow	57-65 L/min (15-17 gpm) 57-65 L/min (15-17 gpm)
Optimal Hydraulic Pressure	150-230 bar (2176-3340 psi) 150-230 bar (2176-3340 psi)
Tip Speed (Depends On Flow)	3,987-5,596 mpm (13,080-18,360 fpm) 3,987-5,596 mpm (13,080-18,360 fpm)
Motor Displacement	6.1 in³/rev 100 cm³/rev
Drive Shaft Torque	152-233 N·m (112-172 lb/ft) 152-233 N·m (112-172 lb/ft)
