Engine

Spec	Value
Engine Model	Cat® C4.4 ACERT™* Cat® C4.4 ACERT™*
Gross Power – Basic	142.1 HP 106 kW
Note	*Meets U.S. EPA Tier 4 Final emission standards. *Meets U.S. EPA Tier 4 Final emission standards.

Weights

Spec	Value
Operating Weight	31879 lb 14460 kg

Operating Specifications

Spec	Value
Rated Load Capacity	10000 lb 4536 kg
Maximum Forward Reach	42 ft 12.8 m
Top Travel Speed	20.5 mile/h 33 km/h
Capacity at Maximum Height (o/r Down)	5000 lb 2268 kg
Maximum Lift Height (o/r Down)	54.9 ft 16.7 m
Capacity at Maximum Reach (o/r Down)	2500 lb 1134 kg
Frame Leveling	10° 10°
Turning Radius – Over Tires	14.1 ft 4.3 m
Drawbar Pull – Loaded	25605 lbf 113.9 kN

Tires

Spec	Value
Standard	400/75-28 Duraforce 400/75-28 Duraforce
Optional	400/75-28 Foam Filled; 14.00-24 Solid; 14.00 × 24 16PR; 14.00 × 24 12PR Foam Filled 400/75-28 Foam Filled; 14.00-24 Solid; 14.00 × 24 16PR; 14.00 × 24 12PR Foam Filled

Hydraulic System

Spec	Value
Pump Type	Variable displacement load sensing axial piston pump Variable displacement load sensing axial piston pump
Auxiliary Hydraulic Flow	25 gal/min 95 l/min
Auxiliary Hydraulic Pressure	3307 psi 228 bar
Note	Auxiliary Hydraulic Circuit used for all attachments equipped with cylinders or other hydraulic components. Auxiliary Hydraulic Circuit used for all attachments equipped with cylinders or other hydraulic components.
System Operating Pressure	3771 psi 260 bar

Service Refill Capacities

Spec	Value
Fuel Tank	38 gal (US) 145 l
Diesel Exhaust Fluid (DEF) Tank	5.7 gal (US) 21.5 l
Hydraulic System	49 gal (US) 185 l

Boom Performance

Spec	Value
Boom Up	15 s 15 s
Boom Down	13 s 13 s
Tele In	16.3 s 16.3 s
Tele Out	18.5 s 18.5 s

Braking System

Spec	Value
Service Brakes	Inboard wet disc brakes on front and rear axles Inboard wet disc brakes on front and rear axles
Parking Brakes	Wet disc, spring applied hydraulic release on front axle Wet disc, spring applied hydraulic release on front axle

Axles

Spec	Value
Types (1)	Trunnion mounted planetary 55 degree steer axles. Trunnion mounted planetary 55 degree steer axles.
Types (2)	High bias limited slip differential on front axle. High bias limited slip differential on front axle.

Work Tools

Spec	Value
Hydraulic IT Coupler	Includes Auxiliary Electrics Includes Auxiliary Electrics
Carriages – Wide Rotate	72 in 1829 mm
Carriages – Side Shift	48 in 1220 mm
Carriages – Swing	100°, 1829 mm, 4536 kg Capacity, 2268 kg Swung (100°, 72 in, 10,000 lb Capacity, 5,000 lb Swung) 100°, 1829 mm, 4536 kg Capacity, 2268 kg Swung (100°, 72 in, 10,000 lb Capacity, 5,000 lb Swung)
Carriages – Standard Rotate	50 in 1270 mm
Lumber Forks – Option 1	[2] 1525 mm, 45 mm × 180 mm ([2] 60 in, 1.75 in × 7 in) [2] 1525 mm, 45 mm × 180 mm ([2] 60 in, 1.75 in × 7 in)
Carriages – Wide Tilt	72 in 1829 mm
Lumber Forks – Option 2	[2] 1829 mm, 50 mm × 150 mm ([2] 72 in, 2 in × 6 in) [2] 1829 mm, 50 mm × 150 mm ([2] 72 in, 2 in × 6 in)
Carriages – Standard Tilt	50 in 1270 mm
Note	*For use with 1829 mm (72 in) Lumber Forks. *For use with 1829 mm (72 in) Lumber Forks.
Pallet Forks – Option 1	[2] 1525 mm, 60 mm × 150 mm ([2] 60 in, 2.36 in × 6 in) [2] 1525 mm, 60 mm × 150 mm ([2] 60 in, 2.36 in × 6 in)
Carriages – Dual Positioning	50 in 1270 mm
Cubing Forks	[2] 1220 mm, 50 mm × 50 mm ([2] 48 in, 2 in × 2 in) [2] 1220 mm, 50 mm × 50 mm ([2] 48 in, 2 in × 2 in)
Fork Extensions*	90 in 2300 mm
Pallet Forks – Option 2	[2] 1220 mm, 60 mm × 100 mm ([2] 48 in, 2.36 in × 4 in) [2] 1220 mm, 60 mm × 100 mm ([2] 48 in, 2.36 in × 4 in)

Transmission Speeds

Spec	Value
Forward	4 speed 4 speed
Reverse	3 speed 3 speed
