Cat

1524 mm (60 in) Pallet Forks

Pallet forks are for moving palletized loads on construction sites, handling bagged fertilizer and seed at landscaping and nursery sites.

Media

Photos

Studio Shot
Studio Shot
Front View
Front View
Top View
Top View
Left View
Left View
Rear View
Rear View
Bottom View
Bottom View
Right View
Right View

Videos

Cat® Forks Attachment at Work
Cat® Forks for Compact Machines at Work
Cat® Forks for Skid Steer Loaders Overview
Cat® Forks for Small Wheel Loaders Overview
An Attachment for Every Job – Cat® Work Tool Attachments

Features

Application

Heavy Duty Backrest

Notched Rail-type Carriage

One Carriage for All Carrying Capacities

Details

Specifications

Spec Value
Height 61 in 1550 mm
Width 98.3 in 2498 mm
Weight 1164.7 lb 528.29 kg
Tine Length 60 in 1524 mm
Tine Width 5.9 in 150 mm
Tine Height 28.5 in 723.5 mm
Tine Thickness 2.6 in 65 mm
Tine Weight 342.4 lb 155.3 kg
Operating Weight 1849.5 lb 838.9 kg
Overall Length 77.8 in 1977 mm
Interface Type IT Coupler IT Coupler
Group Weight 1851 lb 838.9 kg
