Performance

Spec	Value
Cycle Time – Open	1.8 s 1.8 s
Cycle Time – Close	1.2 s 1.2 s
Cutting Force – Blade Center	351 Sh Ton 3125 kN
Crushing Force – Cutter Tip	192 Sh Ton 1710 kN
Crushing Force – Tooth Tip	107 Sh Ton 955 kN

Hydraulic Requirements

Spec	Value
Jaw Circuit – Max. Oil Pressure	5076 lb/in² 35000 kPa
Jaw Circuit – Max. Oil Flow	59 gal/min 225 l/min

Dimensions - Jaw

Spec	Value
Jaw Depth	30.3 in 770 mm
Cutter Length	5.9 in 150 mm
Jaw Opening – Maximum	42.1 in 1070 mm
Jaw Width – Fixed	24.4 in 620 mm

General

Spec	Value
Jaw Width – Moving	13.2 in 335 mm
Height	57.1 in 1450 mm
Width	22.8 in 580 mm
Capacity – Concrete Thickness	26 in 650 mm
Jaw Width – Fixed	17.3 in 440 mm
Length	95 in 2414 mm
Jaw Opening	33 in 838 mm
Jaw Depth	28.4 in 722 mm
Weight	3710 lb 1683 kg
Closing Force – Rebar Cutter	226 Sh Ton 230 t
Closing Force – Tip	117 Sh Ton 119 t

Dimensions - Housing + Jaw

Spec	Value
Length	97 in 2465 mm
Width	24.4 in 620 mm

Weight

Spec	Value
Weight – Housing, Jaw and Bracket	4409 lb 2000 kg

Recommended Carrier Weight

Spec	Value
Excavator Minimum	18000 18000
Excavator Maximum	25000 25000
