Performance

Spec	Value
Cycle Time – Open	1.9 s 1.9 s
Cycle Time – Close	1.4 s 1.4 s
Cutting Force – Blade Center	479 Sh Ton 4265 kN
Crushing Force – Cutter Tip	252 Sh Ton 2240 kN
Crushing Force – Tooth Tip	153 Sh Ton 1360 kN

Hydraulic Requirements

Spec	Value
Jaw Circuit – Max. Oil Pressure	5076 lb/in² 35000 kPa
Jaw Circuit – Max. Oil Flow	95 gal/min 360 l/min

Dimensions - Jaw

Spec	Value
Jaw Depth	36.6 in 930 mm
Cutter Length	7.9 in 200 mm
Jaw Opening – Maximum	50.4 in 1280 mm
Jaw Width – Fixed	26.4 in 670 mm

General

Spec	Value
Jaw Width – Moving	15 in 380 mm
Height	69.1 in 1755 mm
Jaw Width – Fixed	22.8 in 580 mm
Closing Force – Tip	187 Sh Ton 190 t
Length	120 in 3046 mm
Closing Force – Rebar Cutter	387 Sh Ton 393 t
Weight	7542 lb 3421 kg
Capacity – Concrete Thickness	35.4 in 900 mm
Width	27.8 in 708 mm
Jaw Opening	47.8 in 1214 mm
Jaw Depth	43.4 in 1103 mm

Dimensions - Housing + Jaw

Spec	Value
Length	117.9 in 2995 mm
Width	26.4 in 670 mm

Weight

Spec	Value
Weight – Housing, Jaw and Bracket	7628 lb 3460 kg

Recommended Carrier Weight

Spec	Value
Excavator Minimum	32000 32000
Excavator Maximum	50000 50000
