Cat
CB2.7 GC Utility Compactor
Standard Operating Weight with ROPS
5936 lb
2698 kg
Compaction Width
47.2 in
1200 mm
Gross Power
24.6 hp
18.4 kW
Overview
The CB2.7 GC is a 2.7 metric ton machine with 1000 mm (39 in) drums. It’s a versatile machine with a high amplitude and is an excellent match for car parks, shoulders, small parking lots, lane additions, and other similar sized jobs.
Media
Photos
Details
Specifications
Weights
| Spec | Value |
|---|---|
| Standard Operating Weight with ROPS | 5936 lb 2698 kg |
| Maximum Operating Weight with ROPS | 7036 lb 3198 kg |
| Maximum Weight at Rear Drum | 3075 lb 1398 kg |
| Maximum Weight at Front Drum | 2861 lb 1301 kg |
Dimensions
| Spec | Value |
|---|---|
| Compaction Width | 47.2 in 1200 mm |
| Drum Diameter | 28.3 in 720 mm |
| Drum Width | 47.2 in 1200 mm |
| Height – ROPS | 102.2 in 2595 mm |
| Overall Length | 102.2 in 2596 mm |
| Overall Width | 51.7 in 1312 mm |
| Wheel Base | 70.9 in 1800 mm |
Operating Specifications
| Spec | Value |
|---|---|
| Curb Clearance | 17.8 in 453 mm |
| Drum Offset | 2 in 50 mm |
| Ground Clearance | 11.2 in 285 mm |
| Static Linear Load | 66.2 lb/in 11.85 kg/cm |
| Travel Speed – Maximum | 5.8 mile/h 9.4 km/h |
| Turning Radius – Inside Drum Edge | 100 in 2540 mm |
| Turning Radius – Outside Drum Edge | 147.2 in 3740 mm |
Engine
| Spec | Value |
|---|---|
| Gross Power | 24.6 hp 18.4 kW |
| Engine Model | C1.7T C1.7T |
| Net Power – ISO 9249 | 24.4 hp 18.2 kW |
Vibratory System
| Spec | Value |
|---|---|
| Centrifugal Force – Maximum | 6968.8 lb 31 kN |
| Nominal Amplitude – High | 0.02 in 0.52 mm |
Service Refill Capacities
| Spec | Value |
|---|---|
| Water Spray Tank Capacity | 52.8 gal (US) 200 l |
| Fuel Tank Capacity | 14.37 gal (US) 55 l |
Standard Equipment
OPERATOR ENVIRONMENT
- Adjustable Suspension Seat with Operator Presense Switch
- ROPS Folding
- Seat Belt – 75 mm (3 in) high visibility orange
- Operator Console w/ Water Tank Gauge, Emergency Stop, and Glove Box
- 12-volt Power Outlet
- Horn, Backup Alarm
COMPACTON SYSTEM
- Folding Scrapers
- Vibe Selection – front, rear, or both
- Pressurized, Triple-Filtration Spray System with Test Mode
POWERTRAIN
- Auto Engine Off and Auto Warmup
- Air Cleaner, Dual Element
- Engine Belt Guard
TECHNOLOGY
- Telematics
ELECTRICAL
- LED Working Lights
OTHER
- Vandal Protection – lockable hood, fuel fill, and controls cover
- Machine Life and Tiedowns
- Offsets Hitch
Optional Equipment
OPERATOR ENVIRONMENT
- ROPS Fixed
- Sun Canopy
- Seat – Side Shift
- Dual Propel Levers
COMPACTON SYSTEM
- Fixed Scrapers
- Cocoa Mats
- Edge Cutter Ready
- Water Sprayer Antifreeze Kit
- Ballast Kit – 200 kg (440 lb)
- Ballast Kit – 400 kg (880 lb)
POWERTRAIN
- Traction Control
TECHNOLOGY
- Remote Flash / Troubleshoot
- CMV – Compaction Measurement Value
ELECTRICAL
- Battery Disconnect
- LED Roading Lights
- Rotating Amber Beacon
OTHER
- Biodegradeable Hydraulic Oil
- Bumpers
- Single Point Lift
- Custom Paint
