Caterpillar
XQP300
Rating Prime
300 kVA
300 kVA
Frequency
50/60 Hz
50/60 Hz
Voltage
127 - 480 V
127 - 480 V
Overview
This fuel-optimized rental power product is ideal for customers interested in consuming the least amount of fuel. Each model delivers increased flexibility by easily switching between 50 and 60 Hz, which allows one machine to satisfy varying load requirements across diverse regions and applications including mining, manufacturing, oil and gas and construction.
Media
Photos
Videos
360° View
Exterior
360° Exterior view. Double click on the image to zoom in on any area of the product.
Features
Fuel/Emissions Strategy
Cat C9 Diesel Engine
Cat EMCP 4.2B Control Panel
Cat LC5100 Generator
Robust Galvanised Enclosure
Sound Isolated Operator Panel
Cat Connect
Factory Designed, Built and Tested
Worldwide Product Support
500 hr Oil Change Intervals
Improved Transportability
Additional Options Available
Details
Specifications
Generator Set
| Spec | Value |
|---|---|
| Rating Prime | 300 kVA 300 kVA |
| Frequency | 50/60 Hz 50/60 Hz |
| Voltage | 127 - 480 V 127 - 480 V |
Engine
| Spec | Value |
|---|---|
| Engine | Cat C9 Cat C9 |
| Fuel | Diesel Diesel |
Dimensions
| Spec | Value |
|---|---|
| Width | 55 in 1400 mm |
| Height | 84 in 2124 mm |
| Length | 160 in 4065 mm |
| Weight – With Lube Oil and Coolant | 8553 lb 3880 kg |
Fuel consumption Best Fuel Efficiency
| Spec | Value |
|---|---|
| 100% Load 50Hz | 16.5 gal/hr 62.5 l/hr |
| 100% Load 60Hz | 19.4 gal/hr 73.5 l/hr |
| 75% Load 50Hz | 12.5 gal/hr 47.3 l/hr |
| 75% Load 60Hz | 14.7 gal/hr 55.8 l/hr |
| 50% Load 50Hz | 8.9 gal/hr 33.8 l/hr |
| 50% Load 60Hz | 10.6 gal/hr 40.1 l/hr |
Standard Equipment
CAT C9 Diesel Engine
- Turbocharged
Generator
- LC5114N Frame
Air Filter
- Cyclonic/paper with dust cup and service indicator
Cat Connect remote monitoring
- Provides package monitoring and management
Cooling System
- Package mounted radiator with vertical air discharge. Filled from factory
Charging / Starting System
- 24V heavy duty starting motor and charging alternator c/w battery isolator
Fuel System
- Dual wall fuel tank with 3 way directional valve for external supply
Control Panel
- Digital EMCP4.2B set mounted controller
Distribution
- Single, robust enclosure for controls and distribution c/w 4 pole circuit breaker and safety cut off
Structure
- Heavy Duty steel base frame with integral fuel tank. Fork lift pockets. Dragging bars. Lifting frame and 4 point lift. base frame is wider than enclosure to protect generator set during transportation.
Enclosure
- Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance
Exhaust
- Integrated spark arresting silencer
Lube Oil
- On engine primary and secondary oil filters. Filled from factory
General
- Factory tested and inspected
