Standard Equipment

NOTE

• Standard and optional equipment may vary. Consult your Cat dealer for details.

POWER TRAIN - TRACTOR

• Cat® C13 engine with MEUI™
• Cat engine brake
• Electric start, 24 Volt
• Air cleaner, dry type with precleaner
• Fan, hydraulic
• Ground level engine shutdown
• Radiator, aluminum unit core, 9 fins per inch
• Guard, crankcase
• Muffler (only for less or non-regulated regions engine arrangement only)
• Starting aid, ether
• Braking system: – Primary and secondary, wet disc, hydraulic – Parking, hydraulic-released, spring-applied – Throttle lock
• Transmission: – 8-speed planetary power shift – ECPC control – APECS software – Programmable top gear selection – Transmission hold – Differential lock – Guard, power train – Standard tire spin reduction – Ground speed control – Machine speed limit – Differential lock protection

INTEGRATED TECHNOLOGIES

• Sequence Assist and Cat Payload Arrangement

POWER TRAIN - SCRAPER

• Braking system: – Primary and secondary, wet disc, hydraulic

ELECTRICAL - TRACTOR

• Alternator, 150 Amp
• Batteries (4), 12V, 1,000 CCA, maintenance free, high output
• Electrical system, 24V
• Lighting system: – Headlights, halogen – Turn signals with hazard function, LED floodlights, (2) cutting edge (1) bowl, halogen side vision (2)
• Starting/charging receptacle

ELECTRICAL - SCRAPER

• Alarm, backup
• Lighting system: – Brake lights, LED – Turn signals with hazard function, LED

OPERATOR ENVIRONMENT - TRACTOR

• Camera arrangement – WAVS
• HVAC system, heat, AC, defrost
• Thermostat control of HVAC system
• Coat hook
• Lunchbox platform with holding strap
• Diagnostic connection (2)
• 12V power ports (2)
• Differential lock (1)
• Dome courtesy light
• Horn, electric
• T-Handle implement control
• Mirror, rearview
• Radio ready
• ROPS/FOPS cab, pressurized
• Keypad switches: – Throttle lock – Wipers/washers – Hazard lights – Retarding level select – Work lights on, off – Information mode on Messenger Display
• Safety tab rocker switches
• Seat belt, static two-piece
• Seat, Cat Advanced Ride Management (ARM), Cat Comfort Series 3, rotates 30 degrees
• Steering wheel, tilt, telescoping, padded
• Windows, right side emergency egress
• Windows, sliding
• Windows, laminated, zipped in
• Windshield wipers, front and rear windows, includes washers
• Door lock
• Interactive touchscreen vehicle information display
• Gauges, warnings include: – Coolant temperature – Engine oil temperature – Hydraulic oil temperature – DPF temperature – Fuel level – Park brake – Implement lockout – Brake system – Regeneration required – Throttle lock – System voltage – Secondary steering – Bail down – Ejector auto – Differential lock – Apron float – Transmission hold – Cushion hitch – High beam lights – Action lamp – Engine speed, rpm – Gear selection – DEF fill levels

FLUIDS

• Extended Life Coolant to -37° C (-34° F)

OTHER STANDARD EQUIPMENT - TRACTOR

• Advanced cushion hitch
• Accumulators (cushion hitch) with Canadian Registration Number (CRN)
• Fast oil change
• Fenders, non-metallic
• Heater, engine coolant 120V
• Rims (2)
• Tow pin, front
• Vandalism locks
• Heater, engine coolant 120V

OTHER STANDARD EQUIPMENT - SCRAPER

• Fender, scraper
• Bowl: – 18.4 m3 (24 yd3), heaped – 14.1 m3 (18.4 yd3), struck
• Vandalism locks
• Hydraulic position sensing cylinders (bowl lift and apron)
