Cat

2007 mm (79 in) Dozer Blade

Designed for rough and finish grading in dirt, gravel, and light dozing.

Media

Photos

Studio Shot
Studio Shot
Front View
Front View
Top View
Top View
Left View
Left View
Rear View
Rear View
Bottom View
Bottom View
Right View
Right View

Videos

Cat® Blades at Work
Cat® Dozer Blade Operating Tips
Cat® Angle Blade and Dozer Blade Overview
An Attachment for Every Job – Cat® Work Tool Attachments

360° View

Exterior

Features shown represent all Cat® Dozer Blades except where indicated.

Documents

Features

Application

VPAT Design

Replaceable Cutting Edge

Spill Guard

Angled Blade Ends

Mast Mounting Points

Removable Shims

OMM Container

Details

Specifications

Spec Value
Blade Width 79 in 2007 mm
Width – Fully Angled 68.9 in 1750 mm
Maximum Blade Angle – Right/Left of Center 30 degrees 30 degrees
Tilt Angle Range 10° Left/Right 10° Left/Right
Blade Height 24.4 in 619 mm
Overall Height 25.1 in 637 mm
Length 40.5 in 1028 mm
Weight 1014 lb 460 kg
Cutting Edge Thickness 0.6 in 16 mm
Required Hydraulics Standard Flow Standard Flow
Optimal Hydraulic Flow 42-86 L/min (11-23 gpm) 42-86 L/min (11-23 gpm)
Optimal Hydraulic Pressure 145-235 bar (2100-3400 psi) 145-235 bar (2100-3400 psi)
Interface Type Skid Steer Coupler Skid Steer Coupler
